Main Features:
• roll diameter: 80 mm
• extreme exquisite lightweight structure design is easy to carry
• easy paper structure is easy to use and maintenance
• equipped with large capacity rechargeable lithium battery 7.4V,
1500 Ma
• 1.2 meters cement ground height of fall
Multiple wired and wireless interfaces optional
• support the client local program upgrade
• equipped with Windows computer end drive
• equipped with WM, WINCE, Symbian, presentation software and
dynamic
link library Android platform
• Bluetooth host function
Applications:
• copy watch - electrical water meter charge
• Insurance - insurance field fast loss
• warehousing, inventory / distribution / warehousing
• parking - confirm parking time charge of Statistics
• logistics, express transportation invoices / goods delivery order
• mobile sales - ticket / fast consumer goods such as mobile sales
• police and police / management / business field Enforcement /
health supervision
Parts list
leather belt buckle battery serial line USB interface line • rolls
• charger
Detail specification
| Model | MTP-3-B |
| Dimension | 90*120*50mm |
| Weight ( g) | 235 (not including the paper roll) |
| Print method | Line thermal printer |
| Paper width | 80mm |
| print width | 75mm |
| Max diameter of paper roll | 60mm |
| Dot per lie | 384 dots/line |
| internal characters | ASCII CH(8x16,9x17,9x24,12×24); GB18030(16x16,24×24) |
| Print speed | 50~90mm/s |
| Life cycle time | 100km(printing density under 12.5%)/100 million pulses |
| text and graphic Support | English, figure, symbol, Chinese, graph, curve, icon pre-stored,
barcode(CODE39EAN13EAN8 CODABARCODE128CODE93ITF) |
| QR code ,PDF417 |
| Dot pitch (resolution) | 203DPI/8 dots/mm |
| interface | bluetooth,Mini USB |
| Power | 1500mAh 7.4V rechargeable Lithium battery |
| Recharge adapter | Stand by recharging / AC adapter |
| Self-check | Without paper / cover open |
| Black mark test | Supported |
| Paper feeding | Easy paper loading |
| commands | ESC/POS compatible with order sets |
| Paper cut | By hands |
| operate setting | Temperature -10°C~50°C ; Humidity 20%~85% |
| Recharge Setting | Temperature 5°C~40°C; Humidity 20%~85% |
| Storage Setting | Temperature -20°C~70°C ; Humidity 5%~95% |
| Standard accessories | Long-term preservable paper,AC adapter,li-ion battery,USB cable |
| Optional accessories | Serial interface cable/leather case |
| packing list of mobile thermal printer |
| 1: Printer: 1pc |
| 2: Paper roll: 1pc |
| 3: USB Cable: 1 pc |
| 4: charger: 1pc |
| 5: Battery:1pc |
| 6: User Manual: 1pc |
| 7: CD:1pc |
